PTFE Lined Elbow
PTFE Lined Elbow
NB |
F1 |
F |
F2 (G+S) |
| 15 | 44 | 89 | 14.1 |
| 20 | 44 | 89 | 15.7 |
| 25 | 44 | 89 | 17.2 |
| 32 | 51 | 95 | 18.8 |
| 40 | 57 | 102 | 20.5 |
| 50 | 63 | 114 | 22.1 |
| 65 | 76 | 127 | 25.2 |
| 80 | 76 | 140 | 26.8 |
| 100 | 102 | 165 | 26.8 |
SPECIFICATIONS:
1. ALL DIMENSIONS ARE IN mm
2. MATERIAL CONSTRUCTION: ELBOW BODY: ASTM A 234 Gr.WPB FLANGE: ASME B 16.5, ASA 150#,
IS 2062 Gr. A/ ASTM A 105
LINER: ASTM D 4895, PTFE, / PFA, ASTM D 3307, PFA LINER THK. 'S' = MINIMUM 3.0mm
* VENT HOLE
** IN TWO PIECE CONSTRUCTION
*** IN THREE PIECE CONSTRUCTION
